MISSION LX-4 MKII Floorstanding Speaker

The LX MKII Series is the latest in a long line of distinguished Mission loudspeakers, joining the multi-award winning speakers from the mid-level QX Series and the flagship ZX Series. LX MKII maintains the Mission trademark ‘Inverted Driver Geometry’ design, which means the path length between the drivers is optimised. Unique at this price-point, this arrangement allows the precision-tuned crossover to yield improved transient attack and astonishing detail.




Perfected over hundreds of hours of critical listening by Mission’s lead acoustic designer, Peter Comeau, Mission LX MKII utilises trickle-down innovations from the revered ZX series. Improvements in the famous Mission DiaDrive bass unit offer superior control of the low-frequency diaphragm while a refined high-frequency performance and a re-engineered cabinet bracing system further help create a loudspeaker system that outperforms its price-class.




LX-4 MKII Specifications

General description 2-way floorstanding speaker

Enclosure type bass reflex

Bass driver 5"(130mm) composite fibre x2

Treble driver 25mm microfibre dome

AV shield No

Sensitivity (2.83V @ 1m) 89dB

Recommended amplifier power 30-120W

Peak SPL 105dB

Nominal impedance 8Ω Compatible

Minimum impedance 4.3Ω

Frequency response (+/-3dB) 45Hz ~ 20kHz

Bass extension(-6dB) 40Hz

Crossover frequency 3.0kHz

Cabinet Volume (in litres) 29L

Height (on plinth) (900+20)mm

Width 200mm

Depth (with terminals) (265+8)mm

Carton size 385 x 315 x1015mm

Net weight 15.5kg/pcs

Gross weight 18.5kg/ctn
