MICHI X3 Series 2 Integrated Amplifier

The Michi X3 Series 2 Integrated Amplifier offers an unparalleled
listening experience with musical refinement, and breathtaking
detail. Digital audio is rendered utilizing a precision 8-channel
ESS SABRE ES9028PRO DAC configured to dedicate 4 channels
each to the left and right recorded tracks lowering the noise floor,
reducing distortion, and creating an expansive, wide soundstage.
The elegant industrial design of the Michi X3 Series 2 fits
comfortably in any living space while still producing a robust 350
watts from your favorite music sources including Analog RCA
and XLR Balanced, Moving Magnet Phono, aptXTM HD Wireless
Bluetooth, Coaxial, Optical. The PC-USB input supports PCM
(32-bit 384kHz) and Quad DSD (11.2MHz) music files with full
MQA hardware decoding up to 24-bit 384kHz.
Michi X3 Series 2 is built for music lovers and audiophiles alike
with every aspect of its design, engineering, and manufacturing
meticulously refined to deliver exceptional performance. An
oversized in-house manufactured toroidal transformer powers
isolated digital, analog, and high current amplifier circuits further
reducing electrical noise and interference.
Operation and setup of the X3 Series 2 is done with ease utilizing
the included custom Michi IR remote, front panel controls and
large graphic display. Dual Michi-engineered platinum plated
speaker binding posts allow bi-wire and traditional speaker
connections. A full size ¼” (6.35mm) front panel headphone
connection is available for private listening sessions.
RS232 and Ethernet connections ensure simple connection with
automation and control systems.
Michi, expectations amplified

SPECIFICATIONS
Maximum Power Output
Continuous Power Output
Total Harmonic Distortion
Intermodulation Distortion
(60 Hz : 7 kHz, 4:1)
Frequency Response
Phono Input
Line Level Inputs
Damping Factor
(20 Hz - 20kHz, 8 ohms)
Input Sensitivity /
Impedance
Phono Input (MM)
Line Level Inputs (RCA)
Line Level Inputs (XLR)
Input Overload
Phono Input (MM)
Line Level Inputs (RCA)
Line Level Inputs (XLR)
Preamplifier Output Level /
Impedance
Tone Controls
Bass
Treble
Signal to Noise Ratio
(IHF “A” weighted)
Phono Input
Line Level Inputs
Channel Separation
Phono Input
Line Level Inputs
350 watts/channel (4 ohms)
200 watts/channel (8 ohms)
< 0.008%
< 0.03%
20 Hz-20k Hz (+0 dB, +0.4 dB)
10 Hz-100k Hz (+0 dB, -0.4 dB)
350
5.2 mV / 47k ohms
340 mV / 100k ohms
540 mV / 100k ohms
60 mV
3.5 V
5.5 V
1.9 V / 100 ohms
±10 dB at 100 Hz
±10 dB at 10k Hz
80 dB
102 dB
> 55 dB
> 55 dB
Digital Section
Frequency Response
Signal to Noise Ratio
(IHF “A” weighted)
Input Sensitivity/Impedance
Preamplifier Output Level
Coaxial/Optical Digital Signals
PC-USB
Power Requirements
Europe
USA
Power Consumption
Standby Power Consumption
Normal
Network Wakeup
BTU (4 ohms, 1/8 power)
Dimensions (W x H x D)
Front Panel Height
Weight (net)
Finish
20 Hz - 20k Hz (0 ± 0.4 dB)
102 dB
0 dBFs / 75 ohms
1.3 V (at -20 dB Volume Position)
SPDIF LPCM (up to 192kHz 24 bit)
USB Audio Class 1.0
(up to 96kHz 24-bit)
USB Audio Class 2.0
(up to 384kHz 24-bit)*
*Driver installation required
DSD and DoP support
MQA and MQA Studio support
Roon Tested
230 V, 50 Hz
120 V, 60 Hz
500 watts
< 0.5 watts
< 2 watts
1303 BTU/h
485 x 150 x 452 mm
19" x 6" x 17 3/4"
132 mm / 5 1/4"
28.9 kg, 63.7 lb
Black
