NAD C700 V2 BLUOS STREAMING AMPLIFIER

The NAD C 700 V2 BluOS Streaming Amplifier builds on the success of the original C 700 with upgraded digital circuitry, added phono capability, and optional Dirac Live Room Correction (Supports Dirac Live® Room Correction with optional licence and calibration microphone purchase). Its HybridDigital UcD amplifier delivers 80 watts per channel of clean, detailed sound, while advanced digital processing reveals more nuance and presence in every track. Whether you are streaming high-resolution music, enjoying your favourite records, or enhancing TV sound, the C 700 V2 brings out more depth, clarity, and musical expression from every source. With a clear 5-inch display and a compact, modern design, it’s easy to set up, simple to use, and ready to elevate everyday listening.

KEY FEATURES
80 watts per channel of HybridDigital UcD amplification
Refined digital architecture for low-noise, detailed playback
Dirac Live® Room Correction https://nadelectronics.com/pages/dirac with optional licence and calibration microphone purchase
5-inch colour display with album art and system information
Built-in BluOS for high-resolution multi-room streaming
Supports audio up to 24-bit/192kHz with MQA decoding and rendering
Moving Magnet phono stage for turntable connection
HDMI eARC input for seamless TV integration
Supports BluOS-enabled surround sound configurations
Two-way aptX HD Bluetooth and support for popular voice assistants

GENERAL SPECIFICATIONS
Continuous output power into 8 ohms and 4 ohms
>80W / 100W (ref. 20 Hz-20 kHz at rated THD+N, both channels driven) >100 W
THD+N (20 Hz – 20 kHz) at rated power
<0.04 % (250mW to 90W, 4 ohms) <0.04 %
Signal-to-Noise Ratio
>84 dB (A-weighted, 500 mV input, ref. 1 W out in 8 ohms)
Clipping power
>86 W (at 1 kHz 8 ohms 0.1 % THD) >102 W (at 1 kHz 4 ohms 0.1 % THD)
IHF dynamic power
8 ohms: 100 W 4 ohms: 125 W
Damping factor
>90 (ref. 8 ohms, 20Hz to 20kHz)
Frequency response
±0.18 dB (20 Hz - 20 kHz)
Tone controls
Treble: ±6.0 dB at 20 kHz Bass: ±6.0dB at 60 Hz
Channel separation
>93 dB (1 kHz) >72 dB (10 kHz)
Input sensitivity (for 80 W in 8 ohms)
Line In: 550 mV Digital In: -12 %FS
Standby power
>0.5W
SUBWOOFER OUT
Maximum output level
4.0 Vrms (ref 0.0032% THD+N 100 Hz)
Signal-to-Noise ratio
>106 dB (20 Hz-20 kHz, ref 1V out)
THD+N
>0.006 % (20 Hz-200 Hz, ref 1.964V)
Output impedance
600 ohms
BluOS AUDIO
Supported audio file format
https://support.bluos.net/hc/en-us/articles/360000191327-What-Formats-are-Supported-by-BluOS
Sampling rate
up to 32 bit/192 kHz PCM
Bit depths
Bit depths 16 – 24
3rd Party integrations
Airplay 2
Network connectivity
Gigabit Ethernet RJ45
USB
1 x Type-A port for connection to USB memory stick (FAT32 or NTFS formatted) and supported peripherals
Bluetooth quality
aptX HD
Bluetooth connectivity
Two-Way (Receive and Headphone modes)
Supported operating system*
Music playback from network shares on the following desktop operating systems: Microsoft Windows XP, 2000, Vista, 7, 8 to current Windows Operating Systems and macOS versions
Mobile Application
Free BluOS Controller App available for download from the respective App stores of Apple iOS devices (iPad, iPhone and iPod), Android devices, Kindle Fire and Windows or macOS desktops
Supported Radio, Music Services, Integration and Digital Assistants
https://support.bluos.net/hc/en-us/articles/360000191327-What-Formats-are-Supported-by-BluOS
DIMENSION AND WEIGHT
Gross dimensions
218 x 96 x 266 mm 8 5/8 x 3 13/16 x 10 1/2 inches
Net Weight
4.8 kg (10.6 lbs.)
Shipping weight
5.3 kg (11.7 lbs)
