Rotel DX-5 Integrated Amplifier

Rotel DX-5 Integrated Amplifier

The Rotel DX-5 is the ultimate Personal Audio Integrated Amplifier blending cutting-edge technologies, versatile connectivity, packaged in a sleek, elegant, industrial design. Engineered for audiophiles, music lovers, and home entertainment enthusiasts, the DX-5 delivers 33 watts @ 4 ohms (25 watts @ 8 ohms) of classic Rotel Class AB amplification in an ultra size-efficient chassis.

Dimensions (W × H × D)

215 x 76 x 251mm

8 1/2 x 3 x 10"



Front Panel Height

70 mm (2 3/4")



Net Weight

4.1 kg (9.1 lbs.)




The Rotel DX-5 is the ultimate high-performance Personal Audio Integrated Amplifier packaged in a sleek, modern, elegant industrial design. Engineered with passion and driven by a precision Class AB amplifier powered by an in-house wound high-current toroidal transformer delivering 33 watts per channel into 4 ohms (25 watts into 8 ohms).

The premium ESS ES9039Q2M DAC renders the audio with precision and exceptional sound quality on an expansive sound stage. It supports PC-USB (32-bit/384kHz PCM, DSD 4x), Coaxial/Optical (24-bit/192kHz), aptX™ HD and AAC Wireless Bluetooth, legacy RCA analog, and HDMI ARC connectivity with CEC and a subwoofer output.

The DX-5 features a full-color TFT display, 1/4” (6.35mm) headphone jack, and includes an intuitive remote control perfect for music lovers and home entertainment enthusiasts.




Intermodulation Distortion (60 Hz : 7k Hz, 4:1)

< 0.03%



Frequency Response (10 Hz – 80k Hz)

10 Hz – 80k Hz

(0 ± 2 dB, Max)



Input Sensitivity / Impedance

-10.3 dBFS / 75 Ω



S/N Ratio (IHF "A" Weighted)

>100 dB



HDMI

Support ARC function

Digital Inputs

SPDIF LPCM (up to 24-bit / 192k Hz)



PC-USB

USB Audio Class 2.0

(up to 32-bit / 384k Hz )*

*Driver installation required

Support DSD (up to 4X, 11.2M Hz)

and DoP (up to 2X, 5.6M Hz)

Roon Tested
